This Gorgeous ESP32 E-Ink Picture Frame Looks Great on Any Wall, and You Can Make Your Own

Creating a personalized digital art display has never been easier or more accessible, thanks to the power of the ESP32 microcontroller and readily available e-ink displays. This project demonstrates that you don’t need a Raspberry Pi to create a stunning and functional e-ink picture frame. We will guide you through the process of building your own, showing how to leverage the ESP32’s capabilities to create a beautiful piece of technology that seamlessly blends into your home décor. This build offers a sleek, low-power alternative that excels in displaying static images with exceptional clarity. We’ll walk you through every step, from selecting the right components to coding the firmware and assembling the final product.

Why Choose an ESP32 Over a Raspberry Pi for Your E-Ink Picture Frame?

While Raspberry Pis are undeniably powerful single-board computers, they may be overkill for a dedicated e-ink picture frame. The ESP32 offers several advantages in this specific application:

Selecting the Right Components for Your E-Ink Picture Frame

Choosing the right components is crucial for a successful build. Here’s a breakdown of the essential parts and factors to consider when making your selections:

Wiring Diagram and Connections

Connect the ESP32 to the e-ink display according to the following diagram (specific pin assignments may vary depending on the display and ESP32 board used; consult the datasheets for your specific components):

E-Ink Display PinESP32 Pin
VCC3.3V
GNDGND
DINMOSI (GPIO 23)
CLKSCK (GPIO 18)
CSSS (GPIO 5)
DCGPIO 27
RSTGPIO 16
BUSYGPIO 4

Important: Always double-check the pin assignments in the datasheets for your specific e-ink display and ESP32 board to avoid damaging the components.

Setting Up the Development Environment

Before you can start coding, you need to set up the development environment for the ESP32.

  1. Install the Arduino IDE: Download and install the Arduino IDE from the official Arduino website (https://www.arduino.cc/en/software).

  2. Install the ESP32 Board Support Package:

    • Open the Arduino IDE and go to File > Preferences.
    • In the Additional Boards Manager URLs field, add the following URL: https://dl.espressif.com/dl/package_esp32_index.json.
    • Go to Tools > Board > Boards Manager... and search for ESP32.
    • Install the esp32 by Espressif Systems package.

  3. Install Necessary Libraries:

    • Go to Sketch > Include Library > Manage Libraries... and install the following libraries:
      • GxEPD2 (for e-ink display driver)
      • WiFi (for Wi-Fi connectivity)
      • HTTPClient (for downloading images from the internet)
      • ArduinoJson (if you plan to use JSON for configuration or data transfer)

Coding the Firmware: Bringing Your E-Ink Frame to Life

The firmware is the brain of the e-ink picture frame. It handles everything from connecting to Wi-Fi to downloading and displaying images. Here’s a breakdown of the key code sections:

#include <GxEPD2_BW.h>       // For black and white displays
#include <GxEPD2_3C.h>       // For three-color displays (black, white, red/yellow)
#include <GxEPD2_GFX.h>
#include <WiFi.h>
#include <HTTPClient.h>
#include <ArduinoJson.h>

// Replace with your network credentials
const char* ssid     = "YOUR_WIFI_SSID";
const char* password = "YOUR_WIFI_PASSWORD";

// Example image URL
const char* imageURL = "https://example.com/image.jpg";

// Display instance (adjust for your specific display model)
GxEPD2_BW<GxEPD2_750, GxEPD2_750::HEIGHT> display(GxEPD2_750(/*CS=*/ 5, /*DC=*/ 27, /*RST=*/ 16, /*BUSY=*/ 4)); // GDEW075T7

void setup() {
  Serial.begin(115200);
  display.init(115200);
  display.setRotation(1); // Adjust rotation as needed

  // Connect to Wi-Fi
  WiFi.begin(ssid, password);
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }
  Serial.println("WiFi connected");

  displayImageFromURL(imageURL);
}

void loop() {
  // Add code here to periodically update the image
  delay(3600000); // Update every hour (3600000 milliseconds)
  displayImageFromURL(imageURL);
}

void displayImageFromURL(const char* url) {
  HTTPClient http;
  http.begin(url);
  int httpCode = http.GET();

  if (httpCode > 0) {
    if (httpCode == HTTP_CODE_OK || httpCode == HTTP_CODE_MOVED_PERMANENTLY) {
      int len = http.getSize();
      uint8_t buff[1024] = { 0 };  // Buffer for reading data

      // Allocate memory for the image
      uint8_t *imageBuffer = (uint8_t *)malloc(len);
      if (imageBuffer == NULL) {
        Serial.println("Failed to allocate memory for image");
        http.end();
        return;
      }

      WiFiClient * stream = http.getStreamPtr();
      int readLength = stream->available();
      int totalRead = 0;

      while (http.connected() && (len > 0 || len == -1)) {
        // Get available data size
        readLength = stream->available();

        if (readLength) {
          // Read up to the available bytes
          int currentRead = stream->read(buff, ((readLength > sizeof(buff)) ? sizeof(buff) : readLength));

          // Copy data to image buffer
          memcpy(imageBuffer + totalRead, buff, currentRead);
          totalRead += currentRead;
          len -= currentRead;
        }
        delay(1);
      }
      Serial.printf("Image received length %d\n", totalRead);

      // Decode and display image
      decodeAndDisplayImage(imageBuffer, totalRead);

      // Free the memory
      free(imageBuffer);
    } else {
      Serial.printf("HTTP error code: %d\n", httpCode);
    }
  } else {
    Serial.printf("HTTP connection error: %s\n", http.errorToString(httpCode).c_str());
  }
  http.end();
}

void decodeAndDisplayImage(uint8_t *imageBuffer, int imageLength) {
  // Here, you'll need to decode the image (e.g., JPEG, PNG)
  // using a suitable library (e.g., TJpg_Decoder for JPEGs)
  // and then draw it onto the display buffer.

  // This is a placeholder for the image decoding and display logic.
  // The actual implementation will depend on the image format and
  // the specific e-ink display library you are using.

  // Example (replace with actual image decoding and drawing code):
  // display.drawBitmap(0, 0, imageBuffer, display.width(), display.height(), GxEPD2_BLACK);
  // display.update();

  // For example usage, see: https://github.com/Bodmer/TFT_eSPI
  Serial.println("Image decoding and display logic needs to be implemented here.");
  delay(1000);
}

Code Explanation

Important Considerations

Assembling the E-Ink Picture Frame

Once you have the firmware ready and the components tested, it’s time to assemble the e-ink picture frame.

  1. Mount the E-Ink Display: Securely mount the e-ink display in the frame. You may need to use adhesive, screws, or a custom-designed mounting bracket.
  2. Connect the Wiring: Connect the ESP32 to the e-ink display according to the wiring diagram. Ensure all connections are secure and properly insulated.
  3. Install the Electronics: Place the ESP32 and other electronics (e.g., power supply, battery) inside the frame. Ensure there is adequate ventilation to prevent overheating.
  4. Close the Frame: Carefully close the frame, ensuring that all components are properly positioned and the e-ink display is visible.
  5. Power On and Test: Connect the power supply and power on the e-ink picture frame. Verify that the firmware is running correctly and the image is displayed properly.

Customization and Further Enhancements

This project provides a solid foundation for building your own ESP32 e-ink picture frame. Here are some ideas for customization and further enhancements:

Troubleshooting Tips

By following these instructions and using the provided code as a starting point, you can create a stunning and personalized e-ink picture frame that will enhance your home décor. Remember to experiment, customize, and have fun with the project!
