How to Install Custom ROM on Samsung Galaxy Note 5
Standard Note 5 Custom ROM Install Guide
The Samsung Galaxy Note 5 remains an outstanding device for many users, with impressive hardware and an iconic design. Since official software support for this device has ended, installing a custom ROM may give it new life: performance will improve significantly, functions can be expanded upon, and compatibility with new versions of Android is more assured.
This guide provides step-by-step instructions for installing a custom ROM onto the Standard Note 5 to unlock its full potential and get optimal results. Be sure to follow each step for optimal results!
Prerequisites for Installing a Custom ROM on Standard Note 5
Before beginning with the installation process, be certain that you have everything on hand that may be required:
No other steps required! All that’s required for success is having at least 50% battery charge on your Samsung Galaxy Note 5. Your computer should have ADB and Fastboot set up, plus an USB cable to connect your device with it and TWRP downloaded, ready to be flashed.
- Downloadable ZIP with Custom ROM for Samsung Galaxy Note 5 (Optional)
- Magisk ZIP to root after flashing custom ROM
- Backup your data as this will delete everything
Step 1: Enable Developer Options and OEM Unlocking
To root or flash a custom ROM, the first step should be enabling Developer Options and OEM Unlocking.
To Enable Developer Options
- Navigating to [Settings > About Phone**.
- Tapping on Build Number seven times until a message indicates you are now a developer.
To Enable OEM Unlocking
- Navigate to
Settings > Developer Options
. - turning ON OEM Unlocking.
- Turning On USB Debugging and USER Unlocking respectively.
Step Two: Unlocking Bootloader of Samsung Galaxy Note 5
Bootloader unlocking is necessary if you intend on installing a custom recovery and flashing a custom ROM.
Fully power off your device. Boot into “Download Mode” by simultaneously pressing Volumn Down + Home + Power keys on it.
Now connect it via a USB cable to a PC running Odin; download Odin if it isn’t already installed on it.
Boot the device into AP Mode and flash an unlock tool designed for Samsung bootloaders.
Follow on-screen instructions to unlock the bootloader. 6. After unlocking, your device will auto factory reset immediately afterwards.
Step Three : Flash TWRP Recovery on Galaxy Note 5
TWRP Recovery will enable you to flash Custom ROMs or carry out other advanced tasks on your phone.
**1. Install TWRP for Galaxy Note 5 To do so, visit either the official TWRP website or other reputable sources and download an appropriate image file to install TWRP onto your Note 5.
2. Flash TWRP with Odin
- Quickly boot your Note 5 into Download Mode.2. Now connect it via USB to a PC and open Odin, clicking the AP button before selecting TWRP image file from computer.
- Make sure that both Auto Reboot and F.Reset Time options are selected, and tap Start.
- Once flashing has completed, quickly boot into Recovery Mode with Volume Up + Home + Power to complete recovery mode setup.
Step Four: Download and Transfer Custom ROM
Installing a custom recovery allows for the easy flashing of customized ROMs.
1. Install a Custom ROM
Its Some of the more popular options for Galaxy Note 5 users include: (LineageOS is known for its stability and ease-of-use; Resurrection Remix provides customization; Pixel Experience provides stock Android features).
Save the ROM compatible with your device on PC.
2. Move the ROM to Your Device
Connect your device to your PC, and copy your custom ROM’s ZIP file directly into its internal storage.
Step Five : Install Custom ROM via TWRP
Once your custom ROM has arrived on your device, follow these steps to install it:
Boot into TWRP Recovery
- Turn off your device.
- Boot into the TWRP Recovery by pressing Volume Up + Home + Power.
Backup Your Current ROM
In TWRP, navigate to Backup. With these three partitions selected (Boot, System and Data), tap Start Backup. Swipe left or right to start it; this step enables you to recover your device should something go amiss!
To Clear Existing Data**
- Navigating to “Wipe > Advanced Wipe”.
- Check Dalvik Cache, System Cache and Data. Whilst Swiping confirm the operation.
Flash the Custom ROM
- From the main menu, choose Install and navigate to your custom ROM ZIP file.
- Swipe left or right to flash it, then reboot your device when finished.
Step 6: (Optional) Root the Device with Magisk
To gain root access on your Note 5, root it using Magisk:
- Acquire Magisk ZIP File To obtain the Magisk ZIP file, follow this link (magiskmodule.gitlab.io/rom/).
- Flash Magisk in TWRP
- Navigating to TWRP Recovery.
- Select Install from the menu option and install the downloaded Magisk ZIP file.
- Swipe left or right for flashing and reboot your device.
Once your device is up and running with a custom ROM, take these steps to maximize it:
- Install GApps: If your ROM does not come preinstalled with Google Apps, download and flash an appropriate version from GApps for flashing onto your phone. 2. Restore Data**: To restore all your apps and data quickly use apps such as Titanium Backup to quickly restore them all back up again.
- Configure Settings: Take time and discover all of the exciting features offered by your custom ROM.
FAQ
1. Is Rooting Required Before Installing Custom ROM?
No rooting is not necessary but having a custom recovery like TWRP installed will give your device more security when flashing custom ROM.
2. Can I restore to stock firmware?
Absolutely. To revert, use Smart Switch by Samsung or Odin to flash back the stock firmware.
3. Will installing a custom ROM void my warranty?
In most cases, any modifications to software will void its manufacturer’s warranty.
Conclusion
This tutorial on installing a custom ROM on the Samsung Galaxy Note 5 unlocks its true potential, from improved performance and battery life, to access to all recent Android features.
Download all the tools and modules necessary for Android customization by visiting https://magiskmodule.gitlab.io/rom/ and unleash your Note 5’s true power! Now is the time to experience customization like never before with Android customization!
